3. User Setup
3.11.4 Bar length (MAX setting)
L(MAX)
Measuring sensor
New bar
Fast speed
Measuring sensor (on)
New bar
Slow speed
L(MAX): The longest bar placed on the bar rack, the purpose to reduce the bar change time.
MSV80 (1.2M) L(MAX) Setting range : 300mm to 1250mm .
MSV80 (1.5M) L(MAX) Setting range : 300mm to 1550mm .
MSV80 (1.8M) L(MAX) Setting range : 300mm to 1850mm .
Note: All bars must place against to the front side of the bar rack!!!
