Hydrafeed MSV 80 - 11. Appendix: Mechanism; General Tolerance

173
11. Appendix : Mechanism
1
3
2
45678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A3
Rolly
S80-1500(H)
S80
MSV80-1500
1 : 11
2014/11/27
A
Top Cover
Magazine
Extension
Touch Screen
Sliding rail - X axis & Right stand
Sliding rail -
X axis & Left stand
Transformer set
Electrically box
Base
Top Base
Core Unit
