3. User Setup
3.11 Other
3.11.2 Eject remnant
Select 2.< Eject remnant >
- You can choose Eject remnant by pushrod
or Eeject remnant by new bar.
Note: Eject remnant with turret, Eject remnant by New Bar under the conditions as below:
(1) Round Bar (on 3.2.1 )
(2) Single fed components (on 3.5.2 )
(3) Turret comes to loading position function must be under M code finish signal (on 4.8)
(4) To choose new bar waiting position, go to system set up:
Eject remnant by new bar option.
1. Loading new bar and wait
2. Loading new bar to material sensor and wait.
