9. Appendix : Electronic Controller
9.3 Spare Parts List
NO Name
Description
of goods
Placement
E025 PS Power supply /1.5:E
E026 Q1 Isolator interlock switch /1.2:A
E027 QF1 Circuit-breaker /1.3:D
E028 QF2 Circuit-breaker /1.6:C
E029 QF3 Circuit-breaker /1.8:C
E086 QF4 Circuit-breaker /2.2:C
E030 R1 Relay
/12.6:B
/60.2:B
E031 R2 Relay
/12.6:B
/60.2:B
E032 R3 Relay
/12.7:B
/60.2:B
E033 R4 Relay
/12.8:B
/60.2:C
E034 R5 Relay
/12.9:B
/60.2:C
E035 R6(RY303) Relay
/60.2:D
/22.3:E
E036 R7(RY304) Relay
/60.2:D
/22.4:E
E037 R8(RY305) Relay
/60.2:E
/22.6:E
E038 R9(RY306) Relay
/60.2:E
/22.7:E
E039 R10(RY307) Relay
/60.2:E
/22.8:E
E087
E088
E089
E090
E040 RY302 Relay
/21.1:D
/21.1:D
/21.2:D
E041 RYBK Relay
/43.3:B
/43.4:B
/43.4:E
E042 S1 Selector switch /11.4:B
E043 S2 Emergency Stop Button
/5.1:C
/11.5:B
/60.1:F
/60.1:F
