Hydrafeed MSV 80 - Page 155

152
9. Appendix : Electronic Controller
9.3 Spare Parts List
NO Name Description of goods Placement
E044 S3 Safety interlock switch
/5.5:C
/12/3:B
E045 S4 Safety interlock switch
/5.1:E
/12.0:B
E046 S3 KEY Safety interlock switch
E047 S4 KEY Safety interlock switck
E098 S5 Foot switch 12.5:B
E096 S6 Push button + LED lamp
/5.1:A
/5.6:A
E048 SD Servo amplifier
/32.0:B
/33.0:A
E049 SM1 Servo motor /32.3:E
E091
E092
E093
E094
E050 TB1 5.0mm 7 pole /10.1:D
E051 TB2 3.81mm 2 pole /20..0:D
E052 TB3 3.81mm 8 pole /11.1:C
E053 TB4 3.81mm 2 pole /20..7:D
E054 TB5 3.81mm 9 pole
/12.0:D
/12.3:D
E055 TB6 3.81mm 4 pole /20.1:D
E056 TB7 3.81mm 6 pole /20.4:D
E057 TB8 3.5mm 7 pole /21.1:C
E058 TB9 3.81mm 12 pole
/21.1:C
/22.3:C
E059 TB10 3.5mm 8 pole /33.1:E
E060 TB11 3.5mm 4 pole /10.8:B
E061 TB12 3.5mm 3 pole /12.0:A
E062 TB13 3.5mm 11 pole /33.1:C
E063 TB14 3.5mm 5 pole /11.4:A
E064 TB15 3.5mm 3 pole /11.7:A
E065 TB16 3.5mm 14 pole /33.5:C
E066 TB17 3.5mm 3 pole /11.5:A
