8. Warning List
Warning
No.
Warning Picture Cause Action
19
No material!!
Bar feeder checked the
bar inside of spindle,
but it is No material.
(when you select chuck
close bar check)
-Touch on <NEXT>.
-Turn the switch manual
mode.
-Go to reference point.
CNC chuck open
-Again turn the switch auto
mode.
-And start automatic
working.
20
L (MAX) setting too long.
Bar length(MAX setting)
( on 3.11.4), L(MAX)
setting more than the
bar rack’s length.
Refer ( on 3.11.4) L(MAX)
setting range.
21
Feeding many times for
single work piece, you
can not select eject
remnant by new bar.
Select eject remnant by
pushrod (on 3.11. 2).
