Hydrafeed MSV 80 - Page 182

179
1324
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T24105-000X
S80
Main frame set
1 : 8
2015/4/29
A
Q'ty
Part Number
Item
1
T04602-000X
1
1T04603-000X2
1
T04607-000X
3
1
T04608-000X
4
1
T14108-000X
5
2
T14109-000X
6
2
T14703-000X
7
10
Hex socket cap screws-SW Set[M10x1.5x25L]
8
16
Hex socket cap screws-SW Set[M10x1.5x30L]
9
10
Hex socket cap screws[M5x0.8x20L]
10
10
Nut-S Set[M10x1.5]
11
9 6
11
8
5
7 10 4
2
3
1
7
