Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3
-
6
.
.
.
.
±
0
.
1
<
3
.
.
.
.
±
0
.
1
G
e
n
e
r
a
l
T
o
l
e
r
a
n
c
e
A3
Rolly
T04608-000X
S80
Loading connecting rod-R
1 : 2.5
2015/4/29
A
Q'ty
Part Number
Item
1
T14601-000X
1
2
T14606-000X
2
1
T14607-000X
3
1
T14608-000X
4
1
T14618-000X
5
1
T14619-000X
6
1
T14620-000X
7
1
T14622-000X
8
1
T14623-000X
9
4Hex socket cap screws-S Set[M6x1.0x35L]10
3
Hex socket cap screws-S Set[M8x1.25x25L]
11
2
Hex socket cap screws-S Set[M8x1.25x45L]
12
4
Hex socket cap screws[M8x1.25x25L]
13
1
Hex socket cap screws[M8x1.25x30L]
14
2
Nut[M6x1.0]
15
2
Nut[M8x1.25]
16
1
Hex head cap screws[M8x1.25x25L]
17
4
DIN472 Retaining Ring[35]
18
4
DIN472 Retaining Ring[47]
19
2
Washer[8.4x16x3.0]
20
3
Washer[8.5x23x2.0]
21
2
Radial Bearing[6003ZZ]
22
1
Radial Bearing[6004ZZ]
23
4
Radial Bearing[6005ZZ]
24
1
DIN471 Retaining Ring [20]
25
3
Double head round keys[5Bx5Hx15L]
26
25 23
11
21
5
19 3
24
26 4
13 9
14
16
7
10
1
17
16
6
20 12
18 22 2 18 8 13
21
11
15
