190
1
324
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3
-
6
.
.
.
.
±
0
.
1
<
3
.
.
.
.
±
0
.
1
G
e
n
e
r
a
l
T
o
l
e
r
a
n
c
e
A3
Rolly
T24403-000X
S80
Ball screw set
1 : 6
2015/2/11
A
Q'ty
Part Number
Item
1
T04402-000X
1
1
T04404-000X
2
1
T04405-000X
3
1T04406-000X
4
1T04407-000X
5
2
T04408-000X
6
1T04409-000X
7
1
T14424-000X
8
1
T14425-000X
9
1
T14431-000X
10
1
T14433-000X
11
6
Hex socket cap screws-SW Set[M10x1.5x50L]
12
2
Hex socket cap screws-SW Set[M3x0.5x6L]
13
4
Hex socket cap screws-SW Set[M6x1.0x12L]
14
8
Hex socket cap screws-S Set[M10x1.5x30L]15
2
Hex socket cap screws-S Set[M8x1.25x25L]
16
13
Hex socket cap screws[M5x0.8x16L]
17
4
Hex socket cap screws[M8x1.25x45L]
18
2
Washer[8.5x23x2.0]
19
1Encoder[ES38-3F-360-3]
20
2
Thrust Bearing[51105]
21
1
Bearing lock nut[AN05]
22
1
Bearing lock washer[AW05]
23
16 19
5
22 21
23
18
8
12
15
1
4
3
18
20
11
7
17 12
14
6
10 1619
2
13
9
