Hydrafeed MSV 80 - Page 196

193
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T04409-000X
S80
1 : 3
2015/2/11
A
Q'ty
Part Number
Item
2
T14428-000X
1
2
T14437-000X
2
1
T14704-000X
3
6Hex socket cap screws-S Set[M6x1.0x20L]4
2Hex socket cap screws-S Set[M6x1.0x25L]5
4Hex socket cap screws-S Set[M6x1.0x30L]
6
2Hex socket cap screws-S Set[M6x1.0x40L]7
4Hex socket cap screws-S Set[M8x1.25x70L]8
7
5
6 84
1 2
3
