206
1
324
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3
-
6
.
.
.
.
±
0
.
1
<
3
.
.
.
.
±
0
.
1
G
e
n
e
r
a
l
T
o
l
e
r
a
n
c
e
A4
Dean
T27103-002X
S80
Pushrod set - 1200
1 : 8
2017/12/7
A
A
A ( 1 : 4 )
12
4
14
3
17
16
9
1
2
15
5
6 8
13
7
11
10
Q'ty
Part Number
Item
1
T07100-1802
1
1
T17100-1840
2
1
T17102-000X
3
1
T17103-000X
4
1
T17108-000X
5
1
T17109-000X
6
1
T17110-000X
7
1
T17111-000X
8
1Hex socket cap screws-SW Set[M6x1.0x12L]9
1Hex socket cap screws-SW Set[M8x1.25x25L]10
1Hex socket cap screws-S Set[M8x1.25x25L]11
1
Washer[8.4x30x3.0]
12
1
Spring pin[6x10L]
13
2
Set Screw[M6x1.0x12L]
14
2
Radial Bearing[6000ZZ]
15
1
Hex socket flat head screw[M8x1.25x20L]
16
T07100-1902
T17100-1940 (hole dia : 19mm
(dia:19mm Black pushrod)
bush for dia:19mm Black pushrod )
To Next Page
