Hydrafeed MSV 80 - Page 215

212
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Q'ty
Part Number
Item
1
T19110-000X
1
1
T19111-000X
2
4
Hex socket cap screws-SW Set[M6x1.0x20L]
3
1Hex socket cap screws-S Set[M6x1.0x12L]
4
1
Washer[6x19x1.5]
5
1
4
5
2
3
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T29103-000X
S80
Extand Tube
1 : 2
2015/2/11
A
