HT4001 SETUP
CommandTHC for X-Y Table Instruction Manual 3d-5
5
Pierce Complete+
Pierce Complete-
Hold Ignition-
Hold Ignition+
Plasma Start
Plasma Start
24V -
24V +
8
7
6
5
4
3
2
1
J4
A
B
C
C
THC.79
4
3
2
1
J3
Pilot Arc-
Pilot Arc+
Transfer IN-
Transfer IN+
Figure 3d-2 HT4001 power supply interface cable connections
Plasma interface
assembly
Plasma interface assembly
Power supply
CNC
Red wire
Black wire
Black wire
White wire
Black wire
Blue wire
