24 MX3630-01 Rev. J SlideDriver/SlideDriver 50VF Series © 2019 www.hysecurity.com
SlideDriver 50VF-series Wiring Chart (Incoming Power)
The maximum distance shown is from the operator to the power source, assuming that source power is from a
panel box with adequate capacity to support the addition of this motor load. The values are for one operator,
with no other loads applied to the branch circuit. Avoid placing more than one operator to a circuit, but if you
must, be certain to reduce the maximum allowed wire distance by half.
Make sure proper wiring is being used. The following table shows the maximum allowable wire run from the
power source to the operator for various wire sizes. Performance of 50VF-series operators on 1Ø and 3Ø
50 or 60 Hz Power.
NOTE: Distance shown in U.S. Standard “feet.” Metric equivalent shown in parentheses.
SlideDriver 50VF-series Wire Size Chart
Phase Ø 1 1 3 3 3 3
Voltage 208 230 208 230 380 460
Horsepower 2 2 2 2 2 2
VFD Rating
Amps
17.4 17.4 8.7 8.7 5.2 5.2
Wire Gauge Distance Distance Distance Distance Distance Distance
12 90 (27m) 100 (30m) 220 (67m) 240 (73m) 680 (207m) 830 (253m)
10 150 (46m) 170 (52m) 350 (107m) 390 (119m) 1090 (332m) 1310 (399m)
8 240 (73m) 270 (82m) 560 (171m) 620 (189m) 1730 (527m) 2100 (640m)
6 390 (119m) 430 (131m) 900 (274m) 990 (302m) 2750 (838m) 3330 (1015m)
4 620 (189m) 680 (207m) 1430 (436m) 1580 (482m) 4380 (1335m) 5300 (1615m)
2 990 (302m) 1090 (332m) 2280 (695m) 2530 (771m) 6990 (2130m) 8470 (2582m)
Performance of 50VF-series Operators on 1 and 3 Phase, 50 or 60Hz
A HySecurity 50VF-series operators can operate on a wide variety of incoming power.
• 50Hz/60Hz operation with no changes or reconnection
• 1Ø or 3Ø operation by eld rewiring and reconnection. The incoming voltage must match the operator
nameplate. Although the electric motor can be reconnected, a different VFD (motor controller inside
the grey control box) is required between 460V and 208V/230V.
• Any AC powered peripherals such as locks, card readers and other devices need to be checked for
compatibility.
