Table 5: User Menu on page 57 describes the User Menu items and supplies the factory defaults. (Factory
default settings shown in bold.)
Table 5: User Menu
User Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
CT 0 (OFF)
CLOSE TIMER
0 = (OFF) Timer disabled
1 second to 99 seconds
Assign how many seconds before open gate initiates
automatic closure. Keep setting at 0 if a hardwired,
push-button control device is being used.
NOTE: CLOSE TIMER display does not appear when
HOLD TO CLOSE is set to 1.
Not applicable (N/A)
HC 0 (OFF)
HOLD TO CLOSE
0 = off
1 = on
Set to 0 produces a gate closure when a momentary
signal is transmitted. Set to 1 if a constant hold to
close signal, such as a push button control, is being
used. A setting of 1 also deactivates automatic close
timer and causes its menu to disappear. You must set
HC to 1 to comply with UL 325 Type D protection.
Refer to Table Notes.
COM
Close
HO (OFF)
HOLD TO OPEN
0 = off
1 = on
Similar to Hold to Close, but congures the Open
inputs for a constant-hold function.
0 = Momentary open signal
1 = Constant hold open push button required
To comply with UL 325 Type D protection, you must
set HO to 1.
COM
Open
AP 0
AC LOSS
UPS FAIL OPEN
0 = UPS FAIL OPEN
1 = UPS FAIL CLOSE
2 = AUTO OPEN
3 = NO CLOSE TIMER
This menu item only appears if the operator is DC
powered. The setting congures how the gate
functions when AC power fails. For more information,
refer to the supplemental documentation.
COM
Terminal #21
UPS Terminal strip 24
VDC to control box
power disconnect
switch - and +
RO 0 (OFF)
RADIO OPEN/CLOSE
0 = off
1 = on
Congures radio input for open only (0). If changed to
setting 1 then adds capability for radio input to
close gate, but only when gate is fully open.
COM
RADIO Open
BF 2 (ON 2 SEC)
WARN BEFORE OPER
0 = off
1 = warning buzzer on
throughout gate travel
2 = warning buzzer on for
2 seconds of gate travel
3 = warning buzzer on
during gate travel
Controls warn-before-operate buzzer and can be
congured three ways:
Set to 0: Buzzer is disabled. Set at 0, buzzer will still
beep when alerts, faults, errors, or entrapment are
detected.
Set to 1: Buzzer beeps for 3 seconds before gate
motion begins and continues through entire gate
travel.
Set to 2: Buzzer beeps for 3 seconds before gate
motion begins and continues for 2 seconds of gate
travel.
Not applicable (N/A)
FA 0 (OFF)
FORCE OPEN ALERT
0 = off
1 = on
Intended for highly secure facilities.
Set to 1, the operator sounds the 3-second “warn
before operate” buzzer alarm and initiates a closure
if the gate is forced open and the closed limit switch
disengages. The motor starts to secure the gate. If
the gate does not fully close within 4s, the motor
turns off and the buzzer sounds for 30 seconds. The
display shows ALERT 1 - FORCED OPEN.
N/A
