Disassembly and Reassembly
5
5. Use a Phillips screwdriver to remove the three screws on the Type-C adapter board
○
16 , and then
remove the adapter board
○
17 .
6. Disassemble the deputy board kit.
a. Remove the FPC connector on the deputy board
○
18 .
b. Use a Phillips screwdriver to remove the two screws on the deputy board
○
19 .
c. Remove the deputy board
○
20 .
