Chapter 1 RCON-LC System
1.5 Specifications
1-13 ME0416-1A
The specifications regarding the PLC features are as shown below.
Item Specifications
Programming Language LD (Ladder Diagram : Ladder Diagram)
Program Memory 32768 step
Max. Control Axis Quantity 16 Axes
Data Retaining Applicable Items
Ladder Program, OM Comment, Label
Comment
Types of
Commands
Basic Commands 25 commands
Application Commands 56 commands
DFC Commands 35 commands
Calculation
Process
Speed
Basic Commands (LD: Contact)
0.416 s
Basic Commands (OUT: Output)
0.396 s
Application Commands
(MOV: Transference)
1.916 s
Application Commands (B/: Division)
4.833 s
Input and
Output Points
Input Points
0 to 128 points
Output Points
Remote I/O
Points
CC-Link
CC-Link IE Field
6 to 24 words (1 time 1 station to 4 stations)
Input : 96 to 384 points
Output : 96 to 384 points
EtherCAT
EtherNet/IP
PROFIBUS-DP
1 to 16 words
Input : 16 to 256 points
Output : 16 to 256 points
Device
Memory
Output
Input Relay X000 to X07F 128 points
Output Relay Y000 to Y07F 128 points
Support
Relays
For General M0 to M3071 3072 points
For Retaining LM0 to LM255 256 points
For Axis Control AM0 to AM4095 4096 points
For System SM0 to SM127 128 points
Timer
10ms
(0.01 to 327.67 Second)
T0 to T63 64 points
Counter
16-Bit Up
(0 to 32767 counts)
C0 to C63 64 points
Data
Registration
16-Bit for General D0 to D127 128points (32 bits in pair use)
16-Bit for System SD0 to SD63 64points
16-Bit for Joint Indication
IX0 to IX1 2points
Pointer
For JUMP and CALL
Divergence
L0 to L255 256 points (For JE, JMP, CALL
and CALLP Commands, L0 is initial routine,
Constant
Decimal Numbers
16 bits : -32765 to 32767
32 bits : -2.147.483.648
Hexadecimal Numbers (H)
16 bits : 0 to FFFF
32 bits : 0 to FFFFFFFF
To Next Page
