IAI RCON-LC User Manual

Chapter 3 Installation, iring, Conguration
3.2 Wiring
ME0416-1A 3-12
3.2.4 Field network wiring
This manual introduces the example of connecting with a CC-Link master unit with a Mitsubishi
Electric PLC as the host PLC.
[Connecting the host PLC and two RCON-LC systems]
Actuator
Actuator
RCON-LC System
CC-Link dedicated cable
(prepared by the customer)
RCON-LC System
* The terminal
resistor of the CC-
Link master unit is to be
prepared by the customer.
Host PLC
CC
-Link master unit (to be prepared by customer)
Terminal resistor
(supplied with LC unit
