Chapter pecications for unit
2.1
LC unit
ME0416-1A
2-6
2.1.5
External dimensions
The outer dimensi
ons for LC Unit are the sam
e as those for RCON Gateway
Unit.
Item
Specifications
External dimensio
ns
W 30 mm
H 1
15 mm
D 95 mm
Mass
About 170g
Exter
nal view
See figure below
11
5
35.2
39.6
95
98.8
30
7
3.5
40
42
