Chapter 3 Installation, iring, Conguration
3 Installation, Wiring, Configuration
3-1 ME0416-1A
Regarding installation, wiring and setting establishment for RCON-LC System, it is basically the
same as those for RCON System.
In this chapter, states the guideline of installation, wiring and procedures for setting.
For details, refer to RCON System Instruction Manual (ME0384).
Main Differences from RCON System
• Select RCON-LC when it is necessary to select a controller for tool use.
• 0 axis for number of axes to connect and 0 unit for option unit available to select
• The operation mode should be set in Axis Control Command in the DFC commands. (Refer to
3.4 Operation Mode)
To Next Page
