IBM 7212 102 User Manual

About This Guide
This guide describes how to service the 7212 Model 102 Storage Device Enclosure.
It contains the following chapters:
Chapter 1, “General Information,” describes the 7212 Storage Enclosure, gives the
system requirement, discusses SCSI bus cables, and lists hardware specifications.
Chapter 2, “Maintenance Analysis Procedures,” provides the maintenance analysis
procedures (MAPs) required to service the 7212 Model 102 Storage Device
Enclosure.
Chapter 3, “Removal and Replacement Procedures,” provides the removal and
replacement procedures required to service the 7212 Model 102 Storage Device
Enclosure.
Chapter 4, “Servicing the DDS–4, 4mm Tape Drive,” describes procedures to follow
when a problem is detected with an installed 4mm tape drive feature.
Chapter 5, “Servicing the DAT 72, 4mm Tape Drive,” describes procedures to
follow when a problem is detected with an installed DAT 72 tape drive feature.
Chapter 6, “Servicing the VXA Technology Tape Drive,” describes procedures to
follow when a problem is detected with an installed 4mm tape drive feature.
Chapter 7, “Servicing the SLR60 or SLR100 Tape Drive,” describes procedures to
follow when a problem is detected with an installed SLR tape drive feature.
Chapter 9, “Servicing the DVD–RAM Drive,” describes procedures to follow when
a problem is detected with an installed DVD-RAM drive feature.
Chapter 10, “Servicing the DVD–ROM Drive,” describes procedures to follow
when a problem is detected with an installed DVD-ROM drive feature.
Chapter 11, “Parts Diagram and Parts List,” provides the parts diagram and parts
list required to service the 7212 Model 102 Storage Device Enclosure.
Appendix A, “Power Cables,” provides power cable information for different
countries.
Appendix B, “Safety Inspection Procedures,” provides procedures to identify
unsafe conditions when servicing the 7212 Storage Enclosure.
Store this guide with your system manuals.
Related Publications
v 7212 Model 102 Storage Device Enclosure Setup and Operator Guide, SA41-0054,
provides information about installing and operating the 7212 Storage Enclosure.
v IBM Externally Attached Devices Safety Information SA26-2004, provides
translations of danger and caution notices.
© Copyright IBM Corp. 2001, 2004 xi

IBM 7212 102 Specifications

General

Brand	IBM
Model	7212 102
Category	Storage
Language	English
