IBM 7212 102 User Manual

Chapter 10. Parts Diagram and Parts List
This chapter provides the parts diagram and parts list required to service the 7212
Model 102 Storage Device Enclosure.
How To Use This Parts List
AR (As Required) in the Units column indicates that the quantity is not the
same for all machines.
NP (Non-Procurable) in the Part Number column indicates that the part is
non-procurable and that the individual parts or the next higher assembly
should be ordered.
NR (Not Recommended) in the Units column indicates that the part is
procurable but not recommended for field replacement, and that the next
higher assembly should be ordered.
00 00 in the Asm- Index column indicates that the part is either not shown or
not referenced in the illustration.
R (Restricted) in the Units column indicates that the part has a restricted
availability.
Indent
The indenture is marked by a series of dots located before the parts
description. The indenture indicates the relationship of a part to the next
higher assembly. For example:
Indent
Relationship of Parts
(No dot) MAIN ASSEMBLY
(One dot) v Detail or sub assembly parts of a main assembly
(Two dots) v v Detailor sub assembly part of a one-dot sub assembly
(Three dots) v v v Detail part of a two-dot sub assembly
Example of Parts Listing
Asm-
Index
Part Number Units Description
3- 2512667 1 Cover Asm, Rear, Red
2513714 1 Cover Asm, Rear, White
For Next Higher Asm, see Assembly 1-2.
-1 5373637 1 vSeal, Top
-2 5356429 2 vClip, Retaining
-3 1847630 1 vFinger Stock Asm
-4 1847602 NR vvChannel, Finger Stock
-5 5373639 AR vSeal, Bottom
-6 NP 1 vCover, Rear, Without Paint
-7 0416629 R vScrew, Panel
© Copyright IBM Corp. 2001, 2004 65
