IBM 7212 102 User Manual

AS/400 and iSeries Systems
The 7212 Storage Enclosure requires only a supported AS/400 or iSeries system
processor with an OS/400 operating system at level V5R1 (or higher) and a PCI
Magnetic Media Controller (FC 2718 or FC 2768) or a PCI-X ULTRA TAPE
CONTROLLER (FC 5702) or PCI-X TAPE/DASD CONTROLLER (FC 5705). See the
order configurator information for the correct controller to be used for your host
system model.
For a list of supported processors and adapters, contact your IBM marketing
representative or business partner.
SCSI Bus Cables
The following table shows the various SCSI cable feature codes that can be ordered
depending on the host system adapter to which the product will be attached.
Table 1. SCSI Cable Features for pSeries or RS/6000
SCSI Cable Description SCSI Cable Application
1
pSeries &
RS/6000
Adapter
Feature
Length Connectors MES Feature
Cable
Adapter to
7212-102
7212-102 to
2nd Device
3
6203, 6205,
Integrated
Ultra2 SCSI
Adapter, or
Integrated
Ultra3 SCSI
Adapter
(LVD/SE) or
5703, 5710,
5711, 5712
PCI-X
Adapter
0.5 m VHDCI/HD68 5600/9765 Yes Yes
1.5 m VHDCI/HD68 5601/9761 Yes Yes
2.5 m VHDCI/HD68 5602/9762 Yes Yes
4.5 m VHDCI/HD68 5604/9764 Yes No
10 m VHDCI/HD68 5610/9760 Yes No
6206 Ultra
SCSI Adapter
(SE)
0.5 m HD68/HD68 5303/9733 Yes Yes
0.7 m HD68/HD68 5301/9751 Yes Yes
1.5 m HD68/HD68 5300/9750 Yes No
2.5 m HD68/HD68 5302/9752 Yes No
5.0 m HD68/HD68 5305/9755 No No
1
Use Table 3 on page 6 to determine the maximum SCSI cable length per SCSI bus
configuration.
2
The SCSI Terminator feature for all 7212 cable configurations is 5097.
3
Attaching a second device to the SCSI bus after the 7212 Storage enclosure is only
supported when the internal SCSI cable is configured with a single SCSI bus.
Note: For more detailed descriptions of these cables, contact your IBM marketing
representative or business partner.
