IBM 7212 102 User Manual

Asm–
Index
Part
Number
Units Description
1–1 19P4013 1 Power switch assembly
–2 19P4012 1 LED cable asembly
–3 19P3805 1 Power supply
–4 19P4009 1 Cover
–5 19P4450 1 Power distribution cable
–6 19P4011 1 Status interface card
–7 92F0324 1 50 to 68 pin interposer (DVD-RAM only)
–8 19P5037 1 Cable assembly, SCSI-2 internal
–9 19P4010 2 Cooling fan
–10 19P4172 1 Cable, SCSI address (DVD)
–10 19P4169 1 Cable, SCSI address (DDS-4)
–10 19P5591 1 Cable, SCSI address (VXA)
–10 24R0063 1 Cable, SCSI address (SLR60/100)
–11 19P4173 1 Audio jack cable (CD-ROM)
–11 19P4175 1 Audio jack cable (DVD-RAM)
–12 NP 1 Chassis
–13 19P4481 4 Screw, flat head, drive mount
–14 04N5967 1 DVD-RAM drive
–14 97P5716 1 DVD-RAM2 drive
–14 80P2293 1 DVD-ROM drive
–15 19P4898 1 VXA drive
–16 19P1412 1 CD-ROM drive
–17 19P0802 1 DDS-4 drive
–17 18P8779 1 DAT 72 drive
–18 19P4090 1 SLR60 drive
–19 09L5276 1 SLR100 drive
–20 19P4181 1 Drive blank
–21 19P4017 4 Bracket, drive mount
–22 19P4018 1 Label, LED
–23 19P4019 1 Label, IBM logo
–24 19P5078 2 Cable clamp base, rectangular C-clamp
–25 19P5079 2 Cable clamp cover, rectangular C-clamp
–26 59F4585 1 Toroid
–00 19P4756 5 Cable clamp, kwik clip 5/16 inch
–00 19P4757 3 Cable clamp, kwik clip 7/16 inch
–00 19P5080 1 Label, Split SCSI Bus
–00 19P5081 1 Label, Single SCSI Bus
–00 19P0051 1 Device-to-device SCSI bus cable, 0.5 meter HD68-HD68
–00 19P4507 1 Device-to-device SCSI bus cable, 0.5 meter VHDCI-HD68
–00 19P0873 1 Device-to-device SCSI bus cable, 0.7 meter VHDCI-HD68
–00 19P0048 1 Device-to-device SCSI bus cable, 10.0 meter VHDCI-HD68
–00 19P4506 1 Device-to-device SCSI bus cable, 1.5 meter HD68-HD68
–00 19P4508 1 Device-to-device SCSI bus cable, 1.5 meter VHDCI-HD68
–00 19P0279 1 Device-to-device SCSI bus cable, 2.5 meter VHDCI-HD68
–00 19P0050 1 Device-to-device SCSI bus cable, 4.5 meter VHDCI-HD68
–00 19P0052 1 Device-to-device SCSI bus cable, 5.0 meter VHDCI-HD68
–00 19P1307 1 Device-to-device SCSI bus cable, 2.5 meter HD68-HD68
–00 61X8867 5 Rubber foot
–00 19P4482 1 Rack mount hardware kit
–00 19P4016 1 Rack spacer bar
Assembly 1: (continued)
Chapter 10. Parts Diagram and List 67
