Figure 2. Disconnecting the cables from the drive backplane
5. Unscrew the two captive thumbscrews (A) of the drive backplane until fully loose as shown in the
following gure.
If needed, use a Phillips #2 screwdriver to loosen the screws.
Removing and replacing parts in the 9183-22X
5
