138
IBM NeXtScale System Planning and Implem
entation Guide
The F
ront Cable Manag
ement Br
ack
et kit (par
t number 00Y3016) th
at attaches
to the front
of the rack is shown in Figure
5-1
4. This kit includes
f
our brack
ets,
which are enough f
or one rac
k (two br
ack
ets are installed on each side of the
rack).
Figure 5-14 Cable management brack
et
M5 screws
(x10)
M5 clip nut
(x10)
Cable management
brack
ets (x2)
155
