Chapter 5. Rack planning 139
The Cable Routing Tool (part number 00Y3026) that is shown in Figure 5-15 is a
plastic rod to which a cable or cables can be attached by using a hook-and-loop
fastener. After it is assembled, the tool is used to pull the cables through the
cable channels.
Figure 5-15 Cable routing tool
The IBM Rack and Switch Seal Kit (part number 00Y3001) has the following
purposes:
Provides a means to seal the opening in the bottom front of the IBM 42U 1100
mm Enterprise V2 Dynamic Rack. The opening at the bottom front of the rack
must be sealed if a switch is at the front of the rack in U space one.
Provides air sealing of switch mounting rails of switches that are mounted at
the front of a rack and are recessed behind the rack mounting rails. The seal
kit includes enough switch seals for six switches.
