Figure 5-16 shows the components of the IBM Rack and Switch Seal Kit.
Figure 5-16 IBM Rack and Switch Seal Kit contents
Figure 5-17 shows where these pieces are used.
Figure 5-17 Placement of the components of the Rack and Switch Seal Kit
Switch seals
Seal kit foam blocks
Kit contains 12 pieces, enough for
six switches (two per switch)
Kit contains two pieces, enough
for one rack (two per rack)
Front-mounted
switch
Switch
seal
Switch seal
Seal kit foam blocks
