Chapter 7. Hardware management 207
Table 7-10 LED IPMI commands
Table 7-11 Node IPMI commands
Description NetFn CMD Data
Get Sys LED:
Command to
get FPC LED
status
0x32 0x96 Request Data:
None
Response Data:
Byte 1: Completion code (0x00)
Byte 2: SysLocater LED
Byte 3: CheckLog LED
Possible values are 0: Off 1:On 2: Blink (SysLocater LED only)
Set Sys LED:
Command to
set FPC LED
status
0x32 0x97 Request Data:
Byte 1 options:
򐂰 1: SysLocater LED
򐂰 2: CheckLog LED
Byte 2 options:
򐂰 0: Disable
򐂰 1: Enable
򐂰 2: Blink (SysLocated LED only)
Response Data:
Byte 1: Completion code (0x00)
Description NetFn CMD Data
Get Node
Status
0x32 0xa7 Request Data:
Byte 1: Node number: 0x1 to 0x0c for Node 1 to 12
Response Data:
Byte 1: Completion code (0x00) or out of range (0xC9)
Byte 2: Node Power State (0x00: Power OFF; 0x10: S3; 0x20: No
permission; 0x40: Fault: 0x80: Power ON)
Byte 3: Width
Byte 4: Height
Byte 5: Permission state (0x00 Not present; 0x01: Standby; 0x02:
First permission fail; 0x03: Second permission fail; 0x04:
Permission pass)
Reset/reseat
Node
0x32 0xa4 Request Data:
Byte 1: Node number: 0x1 to 0x0c for Node 1 to 12
Byte 2: Reset action: 1: reset, 2: reseat
Response Data:
Byte 1 – completion code (0x00) or cur not support (0x0xd5)
