208 IBM NeXtScale System Planning and Implementation Guide
Show
information
about node size
0x32 0x99 Request Data:
Byte 1: Node number: 0x1 to 0x0c for Node 1 to 12
Response Data:
Byte 1: Completion code (0x00) or out of range (0xC9)
Byte 2: Node Physical Width
Byte 3: Node Physical Height
Byte 4: Add-on Valid
Byte 5: Add-on Width
Byte 6: Add-on Height
Show Node
Power
Consumption in
watts
0x32 0x98 Request Data:
Byte 1 options:
򐂰 Node number: 0x1 to 0x0c for Node 1 to 12
򐂰 Chassis: 0x0d
Response Data:
Byte 1: Completion code (0x00)
Byte 2: Power minimum (LSB)
Byte 3: Power minimum (MSB)
Byte 4: Power average (LSB)
Byte 5: Power average (MSB)
Byte 6: Power maximum (LSB)
Byte 7: Power maximum (MSB)
Description NetFn CMD Data
