The canister is ready with no critical errors when Power is illuminated, Status is on, and Fault is off. If
a canister is not ready, refer to the "Procedure: Understanding the system status using the LEDs" topic
in "Troubleshooting".
3. Wait for all expansion canisters to nish powering on.
4. Power on the control enclosure. Use the supplied power cords to connect both power supply units of
the enclosure to their power sources.
If the power sources have circuit breakers or switches, ensure that they are turned on. The enclosure
does not have power switches.
Notes:
• Each enclosure has two power supply units. To provide power failure redundancy, connect the two
power cords to separate power circuits.
• Review the information on securing the power cables to ensure that each power cable is secured to
each PSU on the back of the enclosure.
5. From the rear of the control enclosure, check the LEDs on each node canister. (See Figure 77 on page
73.)
Figure 77. Node canister LEDs
1 Power
2 Status
3 Fault
The canister is ready with no critical errors when Power is illuminated, Status is flashing, and Fault is
off. If a canister is not ready, refer to the "Procedure: Understanding the system status using the LEDs"
topic in "Troubleshooting".
Chapter 4. Installing the system hardware
73
