Appendix B. Rack mounting templates
This appendix provides duplicate copies of the rack mounting templates. If you want
to tear out the templates from this document, use these copies rather than those
provided in “Installing the support rails” on page 34.
Use the following templates (Figure 92 on page 176 and Figure 93 on page 177) to
identify the proper locations for inserting M5 screws when mounting the support
rails and DS5020 to a rack. The locations for the M5 screws are highlighted in the
templates.
The DS5020 is 3 U high. Align the template with the rack at a U boundary. U
boundaries are shown as horizontal dashed lines in the rack mounting templates.
Note: The mounting holes that are shown in the following templates are square.
The holes in your rack might be round or square.
© Copyright IBM Corp. 2009, 2012 175
