Installing the DIMM air baffle
Use this information to install the DIMM air baffle.
About this task
To install the DIMM air baffle, complete the following steps:
Procedure
Align the DIMM air baffle over the DIMMs so that the baffle pin on the left side of
the air baffle aligns with the pin hole next to DIMM connector 8 on the system
board, and lower it into the server.
Microprocessor 2
air baffle
Hole for baffle tab
Baffle tab
Figure 87. Microprocessor 2 air baffle installation
Chapter 2. Installing optional devices 107
