11. (IBM Business Partners only) Complete the additional steps in “Instructions
for IBM Business Partners” on page 35.
Installing a USB embedded hypervisor flash device
Use this information to install a USB embedded hypervisor flash device.
About this task
To install a hypervisor flash device, complete the following steps:
Procedure
1. Read the safety information that begins on “Safety” on page v and “Installation
guidelines” on page 43.
2. Turn off the server and peripheral devices and disconnect the power cords.
3. Remove the cover (see “Removing the cover” on page 51).
4. Align the flash device with the connector on the SAS/SATA RAID riser-card
assembly and push it into the connector until it is firmly seated.
5. Slide the blue lockbar toward the flash device to the locked position until it is
seated firmly.
Results
If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 106.
Figure 56. USB embedded hypervisor flash device installation
Chapter 2. Installing optional devices 85
