Table 1. Features and specifications (continued)
Integrated functions:
v Integrated Management Module (IMM),
which provides service processor
control and monitoring functions, video
controller, and (when the optional
virtual media key is installed) remote
keyboard, video, mouse, and remote
hard disk drive capabilities
v Broadcom BCM5709 Gb Ethernet
controller with TCP/IP Offload Engine
(TOE) and Wake on LAN support
v Five Universal Serial Bus (USB) 2.0
ports (two front and two rear of the
chassis, and one on the SAS/SATA
RAID riser card in which the optional
USB flash device with embedded
hypervisor software is installed)
v Four Ethernet ports (two on system
board and two additional ports when
the optional IBM Dual-Port 1 Gb
Ethernet Daughter Card is installed)
v One System Management RJ-45 on the
rear to connect to a systems
management network. This system
management connector is dedicated to
the IMM functions. This connector is
active with or without the optional IBM
Virtual Media Key installed.
v One serial port
RAID controllers (depending on the
model):
v A ServeRAID-BR10il v2 SAS/SATA
adapter that provides RAID levels 0, 1,
and 1E (comes standard on some
hot-swap models).
v An optional ServeRAID-BR10i
SAS/SATA adapter that provides
RAID levels 0, 1, and 1E can be
ordered.
v An optional ServeRAID-MR10i
SAS/SATA adapter that provides
RAID levels 0, 1, 5, 6, 10, 50, and 60
can be ordered.
v An optional ServerRAID M1015
SAS/SATA adapter that provides
RAID levels 0, 1, and 10 with optional
RAID 5/50 and SED (Self Encrypting
Drive) upgrade.
v An optional ServeRAID M5014
SAS/SATA adapter that provides
RAID levels 0, 1, 5, 10 and 50 with
optional RAID 6/60 and SED upgrade.
v An optional ServeRAID M5015
SAS/SATA adapter that provides
RAID levels 0, 1, 5, 10, and 50 with
optional RAID 6/60 and SED upgrade.
Size:
v 1U
v Height: 43 mm (1.7 inches)
v Depth: 711 mm (28.0 inches)
v Width: 440 mm (17.3 inches)
v Weight: approximately 15.9 kg (35.1
lb) when fully configured
Acoustical noise emissions:
v Sound power, idling: 6.1 bels
maximum
v Sound power, operating: 6.1 bels
maximum
Electrical input:
v Sine-wave input (47 - 63 Hz) required
v Input voltage low range:
Minimum: 100 V ac
Maximum: 127 V ac
v Input voltage high range:
Minimum: 200 V ac
Maximum: 240 V ac
v Input kilovolt-amperes (kVA),
approximately:
Minimum: 0.090 kVA
Maximum: 0.700 kVA
Notes:
1. Power consumption and heat output
vary depending on the number and
type of optional features installed and
the power-management optional
features in use.
2. The sound levels were measured in
controlled acoustical environments
according to the procedures specified by
the American National Standards
Institute (ANSI) S12.10 and ISO 7779
and are reported in accordance with
ISO 9296. Actual sound-pressure levels
in a given location might exceed the
average values stated because of room
reflections and other nearby noise
sources. The noise emission level stated
in the declared (upper limit)
sound-power level, in bels, for a
random sample of system.
EU Regulation 617/2013 Technical Documentation:
International Business Machines Corporation
New Orchard Road
Armonk, New York 10504
http://www.ibm.com/customersupport/
For more information on the energy efficiency program, go to
http://www.ibm.com/systems/x/hardware/energy-star/index.html
Product Type:
Computer Server
Year first manufactured:
2010
Internal/external power supply efficiency:
PSU 1:
8 IBM System x3550 M3 Type 4254 and 7944: Installation and User's Guide
