2020 LCD Panel
 Battery Pack (1010)
 DIMM Cover (1020)
 Keyboard Unit (1030)
 CD-ROM/FDD Assembly (1040)
 LCD Unit (1070)
 LCD Front Cover (2010)
DSTN LCD Panel
Note: In step .4/, lift the LCD panel a little to disconnect
the flexible cable in step .5/.
Step Size (Quantity) Torque
.1/ M 2.5 x 6mm (4) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
92 IBM Mobile Systems HMM
To Next Page
