LCD Unit, 10.4 SVGA (P/N 29H9227)
3010 LCD Cover
Notes:
1. Be careful not to scratch the LCD cover when
removing the screw covers .1/.
2. The LCD cover has several latches. Release these
latches; then remove the LCD cover. Be careful not
to break the latches.
Step Length (Quantity) Memo
.2/ M2.5 x 6 mm (2)
.3/ M2 x 5 mm (2)
Note: Make sure you use the correct screw when replacing.
302 IBM Mobile Systems HMM
