5020 LCD Panel
 LCD Cover (5010)
Note
Be careful not to scratch or soil the surface of the LCD
panel when replacing it.
Step Length (Quantity) Memo
.1/ M2.5 x 6 mm (3)
Note: Make sure you use the correct screw when replacing.
314 IBM Mobile Systems HMM
