3030 Hinges
 LCD Cover (3010)
 LCD Panel (3020) (with interface cable assembly)
Step Length (Quantity) Memo
.1/ M2.5 x 4 mm (2)
Note: Make sure you use the correct screw when replacing.
306 IBM Mobile Systems HMM
