When removing the interface cable assembly, remove the
kapton tape on the cable; then disconnect the three
connecters as shown.
When replacing
Be careful not to place the core under the LCD panel.
When replacing
Attention:
1. The inverter card is very sensitive. Connect the
interface cable as shown. Flexing the inverter
card with too much force seriously damages the
card.
2. It is not safe to touch the inverter card connecter
.A/. A loose or incorrect connection of the
connector can cause a serious problem.
ThinkPad 760 (9546, 9547) 305
