1060 LCD Assembly
Battery Pack (1030)
Keyboard Unit (1050)
Note: For the LCD FRU removals and replacement, go to
“2010 LCD Front Cover” on page 173.
Step Length (Quantity) Torque
.1/ 4 mm, flathead, Nylon (2) 4.0 kgcm
.2/ 7 mm, Nylon (2) 4.0 kgcm
.3/ 4 mm (1) 3.0 kgcm
Note: Make sure you use the correct screw and tighten it to
the torque specified. Do not use the screw that you removed,
use a new screw.
ThinkPad 560, 560E (2640) 167
