IBM THINKPAD S05L-1270-01 Hardware Maintenance Manual

13.3 XGA, 11J8133
Index Part
1 See LCD cover group
2 LCD Front Cover (See LCD cover group)
3 LCD Panel (13.3 XGA) 11J8185
4 Pinch Rubber 11J8186
5 See LCD cover group
6 Hinges 11J8135
7 LCD Cable Assembly 11J8136
8 See LCD cover group
13.3 XGA, NEC 11J9654
Index Part
1 See LCD cover group
2 LCD Front Cover (See LCD cover group)
3 LCD Panel (13.3 XGA, NEC) 11J9655
4 Pinch Rubber 11J8186
5 See LCD cover group
6 Hinges 11J8135
7 LCD Cable Assembly 11J9657
8 See LCD cover group
LCD cover group 11J8134
Includes the following:
Rear Cover
LCD front cover
Bracket, LCD Structure
Gasket, long
Slide Knob
Slide Plate
Rail Guide, (right/left)
Rubber Bumper
Hinge Cap
Logo (large/small)
Screw Cap
Screw
Note
Do not use the NEC LCD (FRU 11J9654) instead of
the LCD (FRU 11J8133) and vice versa.
510 IBM Mobile Systems HMM
