LCD Unit, 12.1 SVGA (P/N 29H9226,
ASM P/N 29H9029)
1010 LCD Cover
Notes:
1. Be careful not to scratch the LCD cover when
removing the screw covers .1/.
2. The LCD cover has several latches. Release these
latches; then remove the LCD cover. Be careful not
to break the latches.
Step Length (Quantity) Memo
.2/ M2.5 x 8 mm (4)
.3/ M2 x 4.3 mm (6) Flat head
Note: Make sure you use the correct screw when replacing.
ThinkPad 760 (9546, 9547) 291
To Next Page
