Rear View
.1/ Battery pack
.2/ Video in port
.3/ Video out port
.4/ Dolby Digital Output port
.5/ Volume control
.6/ Microphone/line-in jack
.7/ Headphone jack
.8/ Power switch
.9/ Reset switch
.1ð/ Security keyhole
.11/ AC power jack
.12/ External input device port
.13/ Serial port
.14/ Universal serial (USB) port
.15/ Fan louvers
.16/ System expansion port
.17/ Rear infrared port
.18/ External display port
.19/ Parallel port
.2ð/ External diskette drive
.21/ Power-on indicator
.22/ Suspend indicator
.23/ Charge indicator
Note
If the DVD and Enhanced Video Adapter is used, .1/,
.2/, .3/ are available.
608 IBM Mobile Systems HMM
