1130 DSP Card/ Audio (ESS) Card
 Diskette Drive/CD-ROM Drive (1020)
 Battery Pack (1030)
 Hard Disk Drive (1040)
 Top Cover (1060)
 Keyboard Unit (1070)
 LCD Unit (1080)
 Front IR and Rear IR (1090)
 System Board Assembly (1100)
 Upper Shield (1125)
 Video Card (1110)
 DC/DC Card (1120)
Notes:
1. There are two models for 760E, slim type and thick
type. Check the screw length in step .2/ when
removing the DSP card.
2. See the following table and make sure to replace the
correct card.
Slim-Type Models (Models 760C/760E/760L)
Audio (ESS) Card DSP card
760L 760LD 760EL
760ELD 760XL
760C 760E 760CD
760ED 760XD
274 IBM Mobile Systems HMM
