Lift the LCD panel slightly .3/, then disconnect the flexible
cable .4/.
When replacing
Attention: It is not safe to touch the inverter card
connecter .A/. A loose or incorrect connection
of the inverter card connector .A/ can cause a
serious problem. When replacing the inverter
card, make sure the connector is connected
correctly.
ThinkPad 760 (9546, 9547) 315
