System Unit
1 LCD Assembly (11.3 DSTN) 20H4267
(U.S.-2640, model 1xx, 3xx, 5xx)
See “LCD FRU (DSTN)” on page 189 for LCD FRU.
LCD Assembly (12.1 TFT 1) 12J1600
(U.S.-2640, model 2xx, Exx, Fxx)
(These models may instead use TFT 2 below)
See “TFT 1 (12J1600)” on page 190 for LCD FRU.
LCD Assembly (560E, 12.1 TFT 2) 11J9626
(U.S.-2640, model 2xx, 4xx, Exx, Fxx, Hxx)
See “TFT 2 (11J9626)” on page 191 for LCD FRU.
Note for the TFT LCD:
For Model 560, use only the TFT 1 LCD.
For Model 560E:
– When replacing the entire LCD assembly,
use only the TFT 2.
– When replacing an individual LCD FRU,
match the new FRU to the installed FRU.
See “TFT Panel” on page 176 to distinguish
the TFT type.
ThinkPad 560, 560E (2640) 187
