Lift the LCD panel slightly .2/; then disconnect the flexible
cable .3/ and .4/.
When replacing
Attention:
1. The inverter card is very sensitive. Connect the
interface cable as shown. Flexing the inverter
card with too much force seriously damages the
card.
2. It is not safe to touch the inverter card connecter
.A/. A loose or incorrect connection of the
connector can cause a serious problem.
310 IBM Mobile Systems HMM
