Models 380D, 380ED, 385D, and 385ED
.1/.2/: FDD Bezel
.1/.2/.3/.4/ .5/.6/: FDD
Step Size (Quantity) Torque
.1/ M 2.6 x 4mm (1) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
66 IBM Mobile Systems HMM
