Rev 2015-03-02 32
GV10x OPERATION AND SAFETY MANUAL
TABLE C-2 Additional API Commands for GV10x Controllers Manufactured After Jan
15, 2015
New commands supported by PLC program ver. GVP141230.0000.4.ezc (12/30/2014) and later:
[mn ([ for Minimum Watts, mn=05-20)
[mn ([ for Minimum Watts, mn=05-20)
]mn (] for Maximum Watts, mn=49-99)
]mn (] for Maximum Watts, mn=49-99)
wmn (w for Ignite Watts, see mn below )
wmn (w for Ignite Watts, see mn below)
Ignite Watts value range:
mn >= MinWatts or 10, whichever is higher AND mn<=MaxWatts or 70, whichever is lower
sn (s for Ignite Secs, n=0-9)
sn (s for Ignite Secs, n=0-9)
Gn (G for Gauge Type, n=0 or 1
n=0 for MKS Pirani, n=1 for Pfeiffer)
Gn (G for Gauge Type, n=0 or 1
n=0 for MKS Pirani, n=1 for Pfeiffer)
tmn (t for Pressure Trigger, mn=0-60)
tmno (t forPressure Trigger, mn=0-60, o=D,A,a)
o=D means Pressure Trigger Disarmed (always Disarmed if Disabled with t00 command)
o=A means Pressure Trigger Armed (when Torr>Ptrg & RF_NotYetStarted)
o=a means Pressure Trigger Armed (when Torr>Ptrg & RF_NotYetStarted)
Values A and a alternate at ~1Hz and can be used to assist timing of a cycling warning/feedback
light or message
[mn ([ for Minimum Watts, mn=05-20)
]mn (] for Maximum Watts, mn=49-99)
wmn (w for Ignite Watts, see above “Ignite Watts
value range” for mn)
smn (s for Ignite Secs, n=0-9)
Gn (G for Gauge Type, n=0 or 1
n=0 for MKS Pirani, n=1 for Pfeiffer)
t (read Pressure Trigger)
tmno (t forPressure Trigger, mn=0-60, o=D,A,a)
See explanation of o values (D,A,a) above
See 4.2.1.4 for more detail regarding Pressure Trigger and its use in GV10x automation.
The GV10x will respond with ?? if sent an undefined command. For example:
Command Response
X ??
